Starting from:
$25,199
Specifications
- Manufacturer: KTM
- Model: 1390 Super Adventure R
- Year: 2026
- Type: Adventure
- Design: 2-cylinder, 4-stroke, V 75°
- Displacement: 1350 cm³
- Torque: 145 Nm
- Transmission: 6-speed
- CO emissions: 139.5 g/km
- Cooling: Liquid cooled with water/oil heat exchanger
- Engine cylinder: Twin cylinder
- EMS: Keihin EMS with RBW, twin ignition
- Engine oil: Motorex, SAE 10W-50
- Engine stroke: 4-Stroke
- Silencer material: Stainless steel
- Silencer type: Silencer
- Front brake disc diameter: 320 mm
- Rear brake disc diameter: 267 mm
- Front brake: 2 x Brembo 4-piston, radially mounted caliper, brake disc Ø 320 mm
- Rear brake: Brembo 2-piston, fixed caliper, brake disc Ø 267 mm
- Chain: 525 X-Ring
- Frame design: Chromium-Molybdenum-Steel trellis frame, powder coated
- Steering head angle: 64.7 °
- Rear subframe design: Aluminium, powder-coated
- Trail: 112 mm
- Wheelbase: 1577 mm
- Front suspension: WP XPLOR-USD, Ø 48 mm
- Rear suspension: WP XPLOR shock absorber with PDS
- Suspension travel (front): 240 mm
- Suspension travel (rear): 240 mm
- Front suspension adjustment: Compression, rebound and preload adjustment
- Rear suspension setting: Compression (high and low speed), rebound and preload adjustment
- Seat height: 880 mm
- Wheelbase: 1577 ± 15 mm
- Tank capacity (approx.): 23 l
- Ground clearance: 242 mm
- Weight (without fuel): 231 kg
- Weight fully fueled: 248 kg
- Wheelbase tolerance: 15 mm
- Front wheel diameter: 21 "
- Rear wheel diameter: 18 "
- Front wheel width: 2.5 "
- Rear wheel width: 4.25 "
- Wheels: 2.5 x 21"; 4.25 x 18"
- Wheels: Spoked wheels with aluminium rims
